Aurora Signage

LDC32066WPR-V

LDC32066WPR-V

VSPEC range Outdoor

Outdoor P6.6 VSPEC display

LED Cabinet LDC320XX Series 320x320mm Outdoor

Recommended viewing distance

Best for audiences ~6.6 m or further away.

Build your screen
Weight
12 kg
Height
320 mm height
Width
320 mm width
Depth
102 mm depth
Pixel pitch
Pixel pitch 6.6 mm
Brightness
8000 nits brightness

Documents & resources

Anything marked On request isn't published yet — tap to email our team.

BrochurePDF

Marketing overview, key specs and use cases.

Download
Cabinet drawingPDF

Dimensioned engineering drawing for installers.

Download
User manualOn request

Setup, operation and maintenance guide.

Request this document
Product videoOn request

See the cabinet in action.

Request this document

Additional resources

Mirrored from our document library — flyers, install guides, drawings and software you may need alongside this cabinet.

Full specifications

Physical

Cabinet width
320 mm
Cabinet height
320 mm
Cabinet depth
102 mm
Weight
12 kg

Display

Pixel pitch
6.6 mm
Resolution
48 × 48
Pixels per cabinet
9,216
Brightness
8000 nits

Power

Max power
62 W
Average power
17 W

Environmental

Location
Outdoor
IP rating (front)
IP66
IP rating (rear)
IP66

Common applications

This cabinet is regularly specified for the following installation types.

Outdoor advertisingDigital signageStadiumsBillboardsScoreboards

About the VSPEC range

Versatile commercial-grade LED.

The everyday workhorse for transit, retail, sports venues and corporate lobbies. Reliable, serviceable, and ready to scale to any wall size.

Explore the full VSPEC range →

Other VSPEC cabinets

LDC60015SFP-COB-PLUS-L
P1.5 · 600×337.5 mm
LDC1000100059WPR-L
P5.9 · 1000×1000 mm
LDC60012SFP-COB-PLUS-V
P1.2 · 600×337.5 mm
LDC50015TSFP-COB-PLUS-L
P1.5 · 500×500 mm
LDC32066WPR-V FAQ

Common questions about the LDC32066WPR-V

Is the LDC32066WPR-V suitable for outdoor use?
Yes. The LDC32066WPR-V is a weather-rated outdoor LED cabinet (IP66 front), with 8000-nit brightness for sun-readable performance. It is engineered for permanent outdoor installations across Australian conditions.
What viewing distance does the LDC32066WPR-V suit?
As a rough rule of thumb, the minimum comfortable viewing distance in metres is roughly equal to the pixel pitch in millimetres. With 6.6 mm pitch, the LDC32066WPR-V is best for audiences 6.6 m or further from the screen.
How bright is the LDC32066WPR-V?
8000 nits — bright enough for direct sunlight on outdoor signage and stadium scoreboards. Brightness is software-controlled so you can dial it back for evening operation.
What is the LDC32066WPR-V typically used for?
Common applications include Outdoor advertising, Digital signage, Stadiums, Billboards, Scoreboards. Talk to Aurora's team if you'd like to discuss a different use case — most builds combine cabinets across the catalogue.
How do I get a quote for a LDC32066WPR-V screen?
Open ScreenBuilder to spec your wall (cabinets, layout and 3D preview) or request a tailored quote from Aurora's team on 1300 841 542. Pricing is project-based — we factor in install, processing and Australian service support.
