LED Truck Bodies
AU-MOB-BOD03
Truck body (no chassis)
High-impact roadside presence with a premium finished interior — engineered to hold attention.
Technical Specifications
- Screen — left
- 3840×1920mm · pitch P3/P4/P5
- Screen — right
- 3840×1920mm · pitch P3/P4/P5
- Screen — rear
- 1920×1920mm · pitch P3/P4/P5
- Module size
- 320mm(W) × 160mm(H)
- Input voltage
- 3-phase 5-wire 380V
- Output voltage
- 220V
- Hydraulic lifting
- 90° hydraulic screen turnover
- Support legs
- 300mm extension × 4
- Generator set
- 1260×750×1040mm, 16kW
- Video processor
- NovaStar VX400
- Amplifier
- 500W
- Speakers
- 120W × 4
- Packing
- Packed and secured in container
- Container
- 20FR
- HS code
- 8707909000
- Processor option
- Colorlight Z6 Pro · 2.05 Mpx at P3 · 4 of 6 ports
Specifications are from the Aurora Mobile LED Range 2026 catalogue. Contact Aurora to confirm current availability and configuration options.
